FULLAXS(LC) Outdoor Cable Assembly
L’assemblage de câble optique blindé extérieur FULLAXS(LC) est une solution de fibre optique pré-terminée conçue pour les environnements extérieurs exigeants et les connexions réseau à haute fiabilité.It integrates high-quality duplex LC connectors with a robust double-layer armored cable, delivering superior mechanical strength, environmental resilience, and stable optical performance.
Description
Features
* Open bulkhead for easy access to SFP
* IP68 water and dust protection
* Bulkhead cutout allows for removal of transceiver through the bulkhead
* No need to open remote radio head (RRH) for transceiver replacement
* Water proof, dust proof and corrosion resistant
* Plug has tolerance free design, free floating on Z-axis
Product Parameters
| Type | SM-UPC | SM-APC | MM-UPC | |||
| Typical | MAX | Typical | MAX | Typical | MAX | |
| Insertion loss | ≤0.1 | ≤0.3dB | ≤0.15 | ≤0.3dB | ≤0.05 | ≤0.3dB |
| Return loss | ≥50dB | ≥60dB | ≥30dB | |||
| Durability | 500 mating cycles | |||||
| Working temperature | -40 to+85℃ | |||||
